A regulation pickleball court measures 20 feet wide by 44 feet long (6.10 × 13.41 meters), for both singles and doubles. The non-volley zone, commonly called the kitchen, extends 7 feet from the net on each side. Each service court is 10 feet wide and 15 feet long. The net measures 36 inches high at the sidelines and 34 inches at its center. Those measurements come from the 2026 USA Pickleball Official Rulebook, not a tennis-court estimate.
If you are marking a driveway or planning a club facility, remember that a 20 × 44-foot playing court is not enough space for safe movement around the lines. USA Pickleball’s 2026 guidance gives a minimum playing-surface area of 30 × 60 feet and a new-construction recommendation of 34 × 64 feet. Below are the complete measurements, a practical marking sequence, and mistakes to avoid when measuring the net and kitchen.
Official pickleball court dimensions at a glance
| Component | Feet / inches | Metric equivalent |
|---|---|---|
| Playing court width | 20 ft | 6.10 m |
| Playing court length | 44 ft | 13.41 m |
| Distance from net to each baseline | 22 ft | 6.71 m |
| Kitchen (non-volley zone) depth | 7 ft on each side | 2.13 m |
| Each service court | 10 ft × 15 ft | 3.05 m × 4.57 m |
| Net at each sideline | 36 in | 91.44 cm |
| Net at middle | 34 in | 86.36 cm |
| Standard court line width | 2 in | 5.08 cm |
| Minimum surrounding playing surface | 30 × 60 ft | 9.14 × 18.29 m |
| Recommended new-construction surface | 34 × 64 ft | 10.36 × 19.51 m |
For the full current standard, see USA Pickleball’s court construction guidance and official 2026 rules. These requirements apply to singles and doubles alike: there is no separate narrower singles line as in tennis.
How the 20 × 44-foot court is divided
The net divides the 44-foot court length into two equal 22-foot halves. On each half, a horizontal non-volley-zone line runs parallel to the net, 7 feet away. A centerline then divides the 15-foot section between that non-volley-zone line and the baseline into two service courts. That makes each service court 10 feet across and 15 feet deep.
The seven-foot kitchen exists on both sides of the net. It is not seven feet in total. Measured from one non-volley-zone line across the net to the opposite line, the combined kitchen bands span 14 feet along the court length. The two service areas together account for the remaining 30 feet.
Baseline, sideline, centerline and kitchen lines
Baselines form the back edge at each end; sidelines mark the 20-foot width. A centerline splits each service area into right and left halves, but does not continue through the kitchen. Each non-volley-zone line marks the outer edge of the kitchen and is itself considered part of that zone under official rules. Standard lines should contrast clearly with the playing surface.
How big is a pickleball court with its safety area?
One frequent planning mistake is measuring only the 20 × 44-foot playing rectangle and fitting it tightly between fences or walls. Players need room to chase balls beyond sidelines and baselines. The 2026 rulebook specifies a minimum playing surface of 30 × 60 feet. USA Pickleball also recommends 34 × 64 feet for new construction; a facility expecting faster competitive play may benefit from even more runoff space.
| Space type | Width × length | Approximate floor area |
|---|---|---|
| Actual court lines | 20 × 44 ft | 880 sq ft |
| Minimum playing surface including runoff | 30 × 60 ft | 1,800 sq ft |
| Suggested new-construction footprint | 34 × 64 ft | 2,176 sq ft |
These are rectangular space calculations, not construction cost estimates or setbacks mandated by every municipality. Property boundaries, fencing, lighting, accessibility, slope and local approvals can require additional space. The 34 × 64-foot recommendation leaves approximately seven feet of side runoff and ten feet behind each baseline when the 20 × 44-foot court is centered.
Where exactly should a pickleball net go?
Set the net across the center of the 44-foot length, so each baseline sits 22 feet from the net line. Measure net height at the two sidelines, where it should be 36 inches, then measure the middle, where it should be 34 inches. The two-inch dip is intentional, not a defect in the net installation. A basketball or badminton net is not automatically regulation just because it spans the court.
Check the measurement with the net fully installed and tensioned. An incorrectly high center net or low sideline net affects shots near the tape. A portable system should be rechecked after moving it, particularly on uneven driveways or temporary surfaces.
How to mark a temporary pickleball court step by step
- Choose the surface. Use a dry, reasonably level area with traction and enough room for safe runoff, not just the 20 × 44-foot lines.
- Establish the center net line. Mark the midpoint across the intended 44-foot playing length.
- Measure 22 feet to each baseline from the net centerline. Verify the distance along both sidelines.
- Measure a 20-foot width and mark the court’s four corners. Check both diagonals match so your rectangle is square rather than a parallelogram.
- Draw the non-volley-zone lines parallel to the net, exactly seven feet into each half.
- Add the center service lines through the 15-foot-deep areas between each baseline and kitchen line. Divide the 20-foot width in half.
- Install and measure the net at the correct 36-inch side and 34-inch center heights.
- Inspect all lines and the runoff area before anyone plays. Use suitable removable court tape if this is a temporary layout.
Measure to the appropriate outside edges as described by the USA Pickleball court specification instead of blindly measuring from the middle of thick tape. For a permanent installation, use the official construction resource and consult a court contractor where drainage, surfacing or lighting work is involved.
Are pickleball court dimensions the same for singles and doubles?
Yes. In both formats, the full legal playing rectangle is 20 feet by 44 feet. Singles changes where one person must move and how they cover the service court, not the official width or length of the lines. In doubles, the two teammates each help cover the same court. Do not add tennis-style singles sidelines when converting a court for pickleball.
If you’re learning how these boundaries apply during play, our pickleball rules guide explains serves, kitchen faults and scoring. The third-shot-drop tutorial shows why the non-volley-zone line matters strategically.
Why the kitchen line matters to gameplay
Players cannot volley the ball—that is, hit it out of the air without a bounce—while touching the non-volley zone or its line, and the rule also covers relevant momentum afterward. Entering the kitchen is not automatically a fault: players can step in to play a ball that has bounced. It is the volley action in or connected to the zone that creates the issue.
The 7-foot non-volley-zone depth affects dinks, drop shots and positioning at the net. Beginners sometimes assume the kitchen is only the painted rectangle and its boundary line is safe to stand on when volleying; under the rules, that line counts as part of the zone.
Pickleball court vs. tennis, badminton and padel
| Sport | Relevant playing rectangle | Key difference |
|---|---|---|
| Pickleball | 20 × 44 ft | Same footprint for singles and doubles; 7-foot kitchen per side |
| Badminton doubles | 20 × 44 ft | Same outer rectangle length and width but different net, markings and movement rules |
| Tennis doubles | 36 × 78 ft | Substantially larger court and a different net/line layout |
A badminton doubles court has the same outer nominal dimensions, but that does not make its markings or net interchangeable. Tennis facilities can sometimes add pickleball lines within existing outdoor areas, but any conversion needs suitable clearances around each pickleball playing rectangle. For a different racket sport that uses surrounding walls, read our padel versus pickleball comparison.
Common pickleball court measuring mistakes
| Mistake | Correct rule |
|---|---|
| Using a 20 × 44-ft fenced space | Those are court line dimensions; add proper runoff space beyond the lines. |
| Making the kitchen seven feet total | The kitchen extends seven feet from the net on each side. |
| Setting the net to 36 inches throughout | It is 36 inches at sidelines and 34 inches at the center. |
| Using separate singles lines | The same 20-foot court width applies to singles and doubles. |
| Drawing a centerline inside the kitchen | Service centerlines divide the service areas, not the non-volley zone. |
| Using a very narrow court tape | Official line width is two inches; use contrasting, clearly visible markings. |
Frequently asked questions
How many square feet is a pickleball court?
The official playing lines enclose 880 square feet (20 × 44). With surrounding playing space, the minimum 30 × 60-foot footprint is 1,800 square feet, and the recommended new-construction 34 × 64-foot footprint is 2,176 square feet.
How far is the kitchen line from the pickleball net?
Seven feet on either side. The non-volley-zone line is part of the kitchen.
Is a pickleball court smaller than a tennis court?
Yes. Regulation tennis doubles dimensions are 36 × 78 feet, whereas pickleball is 20 × 44 feet.
Are there different dimensions for singles?
No. A standard pickleball court is the same length and width for singles and doubles.
How wide is each service box in pickleball?
Each service box is approximately 10 feet wide and 15 feet deep, measured within the court geometry.
Is a 30 × 60-ft yard enough for pickleball?
That matches the minimum playing-surface dimensions in the 2026 USA Pickleball rules, assuming a suitable rectangular surface and correct positioning. Whether a specific yard is safe or compliant also depends on obstacles, slope, construction, permits and runoff needs.
What is the recommended outdoor pickleball court size?
For a new dedicated court including runoff, USA Pickleball recommends 34 × 64 feet, while the official painted court remains 20 × 44 feet.
Official sources and the bottom line
These figures were cross-checked with USA Pickleball’s 2026 rulebook and its court construction guidelines. The essential numbers are easy to remember: 20 × 44 feet for the lines, 7 feet for each kitchen, and 36/34 inches for net height. If you’re designing a permanent court, add proper safety space instead of treating the painted rectangle as the full construction footprint.
